AtlasIED SM195-89 Surface Mount Clock / Speaker Enclosure Mounts 840-89A Baffle

Use AtlasIED 195 Series protective enclosures for recessed or surface mounting of 840 Series clock/speaker baffles. The 195 Series has 12 knockouts (four on both top and bottom, two at each end). Enclosures are constructed of 20-gauge CRS and are heavily undercoated to prevent mechanical resonances. Units contain a compartment divider to separate high and low voltage wiring. Models for surface application include an (SM) prefix and are finished in textured white epoxy to match the clock/speaker baffle panel. Recessed enclosures are finished with an epoxy coating.

FEATURES

• All Models Include Provisions for Easy Installation of Standard 8" Loudspeakers.
• Easy-to-Configure Standard Panels in Model NC850 Provide Custom Flexibility for Mounting Switches, Thermostat, and/or Lighting Controls.
• Recessed and Surface Mounting Styles Meet Installation Requirements.
• Reliable Design Installs Quickly in New or Retrofit Construction
