FEATURES
- 30W into 25V/70.7V and 4Ω Loads
- Rear Mounted DIP Switch Allows Mute Receive for Inputs 2 and 3
- Contact Closure Mute Terminals
- Variable Mute Sensitivity Control for Input 1
- Two Unbalanced, Summing Line Level Inputs
- Balanced Mic/Line/Tel Input w/ Phantom Power
- Automated Diagnostic System Test (Push Here Diagnostic)
SPECIFICATIONS
Frequency Response - 50Hz - 15kHz
Power Output - Max. Average Power @ 50Hz-15kHz with .5% THD, 4Ω 30W RMS
Height - 3.66" (93mm)
Width - 8.27" (210mm)
Depth - 10.87" (276mm)
Weight - 9lb
Shipping Weight - 11lb
Voltage Compatibility - 110V - 120V
